Swing Clamp Cylinder

Tulasi Hydraulic Pvt. Ltd. is a leading Manufacturing company located in Mumbai, specializing in Swing Clamp Cylinder. As a trusted Manufactures and Suppliers, we are dedicated to providing high-quality hydraulic solutions that meet the specific requirements of various industries. Our role as a Provider and Exporter allows us to effectively serve both domestic and international markets, ensuring our products comply with the highest quality standards. With extensive experience as Fabricators and Dealer in the hydraulic sector, we proudly serve clients in Navi Mumbai, Thane, and throughout India, delivering reliable products and exceptional service that our customers can depend on.

A swing clamp cylinder, also known as a swing clamp or swing cylinder, is a type of hydraulic or pneumatic actuator designed for clamping and securing workpieces or tools in various industrial applications. These cylinders provide a swinging or pivoting motion to engage or disengage clamping devices, making them useful for applications that require quick and reliable clamping, holding, or positioning of objects. The main body of the swing clamp cylinder contains the internal components and provides structural support. It typically has a pivoting or swiveling axis that allows it to swing in an arc. Swing clamp cylinders have hydraulic or pneumatic ports for the inlet and outlet of hydraulic fluid or compressed air. These ports control the actuation and release of the clamp. Inside the cylinder body, a piston is connected to the swinging arm. The piston is actuated by hydraulic pressure or compressed air and is responsible for the swinging motion of the clamp. The swinging arm, also known as the clamping arm, is attached to the piston and extends outside the cylinder body. It holds the clamping device or fixture that secures the workpiece. Swing clamp cylinders are used in conjunction with various clamping devices, such as clamps, grippers, or jaws, depending on the specific application. These devices securely hold the workpiece or tool in place when the clamp is engaged. Like other hydraulic or pneumatic cylinders, swing clamp cylinders have sealing mechanisms to prevent fluid or air leakage during operation. Seals are essential to maintain the integrity of the system and ensure efficient clamping. Swing clamp cylinders are controlled using hydraulic or pneumatic control valves that regulate the flow of fluid or air to the cylinder. These valves allow operators to control the clamping and releasing actions. Swing clamp cylinders can be mounted in various orientations to accommodate different clamping requirements, including horizontal, vertical, or angular positions.

Swing clamp cylinders are used in CNC machining centers to secure workpieces during milling, drilling, or other machining operations. In welding applications, swing clamp cylinders hold workpieces or welding fixtures in position for accurate and repeatable welding processes. They are employed in assembly lines to secure components during assembly, ensuring proper alignment and fastening. In metal stamping and forming operations, swing clamp cylinders are used to hold and release dies quickly for die changes. Swing clamps secure molds in place during plastic injection molding, allowing for efficient and precise molding processes. Swing clamp cylinders are used in woodworking machinery to secure wood pieces during cutting, shaping, and milling operations. They find use in robotic systems to hold and position objects for pick-and-place operations or for interfacing with automated tools. Swing clamp cylinders play a critical role in enhancing productivity and precision in manufacturing and assembly processes by ensuring that workpieces are securely held in position during various operations. Their rapid clamping and unclamping capabilities make them valuable tools in applications where efficiency and accuracy are paramount.

Swing Clamp Cylinder

Application :

  • As per ISO Standard
  • Tierod construction as well as welded construction.
  • Min. bore O 25 mm to Max. bore 5771 mm.
  • Working pressure. a) 140 kg/cm2, b) 350 kg/cm2
  • Stroke length upto 6.5 metres
  • Telescopic cylinders as per customer’s requirements.
  • Cylinders available. In S S For Pharmaceutical Machinery.
