Telescoping Cylinders
Tulasi Hydraulic Pvt. Ltd. is a leading Manufactures and Suppliers of high-performance Telescoping Cylinders, based in Mumbai, with additional operations in Navi Mumbai and Thane. As a trusted Provider and Exporter, we specialize in fabricating cutting-edge hydraulic solutions designed to meet the diverse demands of various industries. Our Manufacturing company is committed to delivering reliable and efficient products, making us a preferred Dealer in the hydraulic equipment market. With a strong emphasis on quality and innovation, Tulasi Hydraulic Pvt. Ltd. continues to set benchmarks in the industry across India and beyond.
Telescoping cylinders, also known as telescopic hydraulic cylinders or multistage cylinders, are a type of hydraulic actuator designed to provide long linear strokes in applications where limited space is available for a cylinder's extended length. These cylinders consist of multiple nested stages or tubes, each with progressively smaller diameters, which allows them to collapse and extend like a telescope. Telescoping cylinders are widely used in various industrial applications where extended reach or height adjustment is required. Telescoping cylinders consist of multiple cylindrical stages, usually three to five, that are nested inside each other. Each stage has a different diameter, with the smallest stage inside and the largest stage on the outside. Telescoping cylinders have hydraulic ports for the inlet and outlet of hydraulic fluid. These ports control the extension and retraction of the cylinder. Inside the innermost stage, there is a piston rod attached to a piston. When hydraulic pressure is applied to the piston, it generates a force that extends or retracts the telescoping stages. Telescoping cylinders are equipped with sealing mechanisms at each stage to prevent hydraulic fluid leakage and maintain pressure integrity. Seals ensure efficient operation and protect the internal components from contaminants.
Telescoping cylinders are controlled using hydraulic control valves that regulate the flow of hydraulic fluid to the cylinder. These valves allow operators to control the extension and retraction of the telescopic stages. Telescoping cylinders can be mounted in various orientations and configurations to suit the application's requirements. Common mounting options include clevis mounts, flange mounts, and trunnion mounts. The load attachment or end fitting is the part of the piston rod that connects to the load or application being moved or adjusted. Load attachments can vary in design depending on the specific application. Telescoping cylinders are used in scissor lifts, cherry pickers, and boom lifts to raise and lower the work platform to different heights. They are employed in dump trucks to raise and lower the bed for unloading materials. Telescoping cylinders are used in farm machinery such as loaders and forklifts for lifting and positioning tasks. They are found in conveyor systems and material handling equipment for extending and retracting conveyor sections. Telescoping cylinders are used in construction equipment like backhoes and excavators for various tasks, including digging and lifting. They are used in fire trucks to extend and retract ladder sections for firefighting and rescue operations. In furniture and office equipment, telescoping cylinders are used to adjust the height of tables and desks. Telescoping cylinders are used in stage equipment and theater rigging to raise and lower stages, lighting, and scenery.
Application :
- As per ISO Standard
- Tierod construction as well as welded construction.
- Min. bore O 25 mm to Max. bore 5771 mm.
- Working pressure. a) 140 kg/cm2, b) 350 kg/cm2
- Stroke length upto 6.5 metres
- Telescopic cylinders as per customer’s requirements.
- Cylinders available. In S S For Pharmaceutical Machinery.
