Tie-rod Hydraulic Cylinder
Tulasi Hydraulic Pvt. Ltd. is a prominent Manufacturing company based in Mumbai, specializing in Tie-rod Hydraulic Cylinder. As a leading Manufactures and Suppliers, we are dedicated to providing high-quality hydraulic solutions that cater to the diverse needs of various industries. Our role as a Provider and Exporter enables us to serve both domestic and international markets, ensuring our products meet the highest quality standards. With extensive experience as Fabricators and Dealer in the hydraulic sector, we proudly serve clients in Navi Mumbai, Thane, and throughout India, delivering reliable products and exceptional service that our customers can trust.
A tie-rod hydraulic cylinder is a type of hydraulic actuator commonly used in industrial and mobile hydraulic systems. It is designed to provide linear motion, such as pushing, pulling, or lifting, by converting hydraulic pressure into mechanical force. Tie-rod cylinders get their name from the tie rods that connect the cylinder's end caps, helping to secure and maintain the structural integrity of the cylinder. The cylinder barrel is the cylindrical housing that contains the piston and hydraulic fluid. It is typically made of high-strength steel and is precision-machined to ensure smooth movement of the piston. The piston is a key internal component of the hydraulic cylinder. It is a cylindrical piece that moves inside the cylinder barrel. When hydraulic pressure is applied to one side of the piston, it generates a force that moves the piston and the attached rod in a linear direction. The rod, also known as the piston rod or shaft, extends from the piston through one end of the cylinder barrel. It is the part of the cylinder that connects to the load or the application that requires linear motion. The rod transmits the force generated by the piston to the external load. Tie-rod cylinders have two end caps, one at each end of the cylinder barrel, that securely seal the hydraulic fluid inside the cylinder. These end caps are often made of durable materials, such as steel or cast iron, and are threaded or bolted to the cylinder barrel. Tie rods are threaded rods or bolts that pass through holes in the end caps and secure them to the cylinder barrel. They play a crucial role in maintaining the structural integrity of the cylinder by preventing the end caps from separating under pressure. The number and size of tie rods can vary depending on the cylinder's design and capacity.
Tie-rod cylinders are equipped with seals to prevent hydraulic fluid leakage. Common seals include piston seals, rod seals, and wiper seals. These seals help maintain pressure and protect the internal components from contaminants. Hydraulic fluid enters and exits the cylinder through hydraulic ports located in the end caps. These ports are connected to the hydraulic system and control the flow of fluid into and out of the cylinder. Tie-rod cylinders can be mounted in various orientations and configurations, depending on the application's requirements. Common mounting options include flange mounts, foot mounts, and clevis mounts. Tie-rod cylinders are used in forklifts, scissor lifts, and other material handling equipment for lifting and positioning loads. They are found in construction equipment such as excavators, backhoes, and loaders for various tasks, including bucket movement and boom control. Tie-rod cylinders are used in agricultural equipment like tractors and harvesters for tasks such as raising and lowering implements. They are employed in machine tools like hydraulic presses and shears for various metalworking processes. Tie-rod cylinders are used in mobile hydraulic applications such as dump trucks and refuse collection vehicles for lifting and dumping loads. They are used in various automation systems for precise linear movement, including conveyor systems and robotics. Tie-rod cylinders are used in oil and gas equipment, including drilling rigs and wellhead control systems.
Application :
- As per ISO Standard
- Tierod construction as well as welded construction.
- Min. bore O 25 mm to Max. bore 5771 mm.
- Working pressure. a) 140 kg/cm2, b) 350 kg/cm2
- Stroke length upto 6.5 metres
- Telescopic cylinders as per customer’s requirements.
- Cylinders available. In S S For Pharmaceutical Machinery.
